LCD Panel

Panel Dimensions

55 inch

Backlight

DLED

LCD Technology

IPS/VA

Aspect Ratio

16: 9

Brightness

500 cd/m² (typ.)

Contrast

IPS 1200:1(typ.) / VA 4000:1(typ.)

Display Colors

10 bit (8 bit + FRC), 1.07B colors

Resolution

3840 (H) × 2160 (V)

Viewing Angle

178° (H); 178° (V)

Response Time

8 ms (typ.)

Surface Treatment

Haze 1%

Built-in System

Operating System

Android 8.1

CPU

4 cores A17, 1.6 GHZ

RAM

2 GB

ROM

16 GB

Video Decoding

2-ch H.264 1080p@25 fps; 4-ch H.265 1080p@25 fps;

4-ch H.265 1080p@30 fps; 2-ch H.264 1080p@25 fps;

2-ch H.265 1080p@30 fps; 2-ch H.264 4K@25 fps; 2-ch

H.265 4K@30 fps; 1-ch H.265 4K@60 fps; The decoding

capacity statistics are based on tests with a single video

file.

Function

Audio Compression

MPEG-3, WMA, WAV

Video Compression

MPEG-4, H.264/AVC, H.265/HEVC

Video Format

mp4, avi, mov, asf, mkv, wmv

Device Ports

Network Port

1 × RJ–45 10/100/1000 Mbps self-adaptive Ethernet

port

Wi-Fi

Optional (External Wi-Fi module)

Bluetooth

NO

Data Transmission Ports

1 × TF card slot, up to 128 GB

2 × USB 2.0 ports (type A)

Video Input

1 × HDMI 1.4 (1080p @60Hz)

Video Output

NO

Audio Port

1 × 3.5 mm jack Mic

IR Receiver

Yes

Speaker

Built-in Speaker

2 × 5 W

General

Power Supply

100–240 VAC, 50/60 Hz

Power Consumption

≤150 W

Standby Power

Consumpton

≤ 0.5 W

Operating Temperature

0 °C to +40 °C (+32 °F to +104 °F) (avoid direct sunlight)

Storage Temperature

–20 °C to +60 °C (–4 °F to +140 °F)

Operatng Humidity

10%–85% (RH), non-condensing

Storage Humidity

10%–90% (RH), non-condensing

Product Material

Metal casing

Casing Color (Frame/Rear)

Black

Product Dimensions

1222.5 mm × 694.8 mm × 57.9 mm (48.13″ × 27.35″ ×

2.28″) (without bracket)

Packaging Dimensions

1357 mm × 150 mm × 853 mm (53.43″ × 5.91″ × 33.58″)

Net Weight

15.5 kg (34.17 lb)

Gross Weight

22 kg (48.50 lb)

Installation

Wall mount

Display Mode

Landscape/Portrait

Wall Mount VESA

400× 400mm

Accessory

Wall-mount bracket, power cord, legal and regulatory

information, energy label, user’s manual, remote control

Certification

Certifications

CE; ERP
